Introducing the Patriot All-In-One Mobile Data Computer

RadioMobile’s All-in-One MDC is a state-of-the-art solution that features a built-in Intel i5 computer with a 12.1” high bright touch screen display. Built fanless with no moving parts, the Patriot takes pride in a standard configuration of 120GB solid state drive and 8GB RAM with upgrade options. It also offers plenty of USB 3.0 and 2.0 peripherals along with options to plug in an additional HDMI display, Ethernet and/or Serial devices and WiFi capability.

  • 12” high bright mobile display
  • Optional keyboard
  • Competitive pricing
  • Public/private network compatibility
  • Ruggedized design for in-vehicle use

  • Intel i5 Processor
  • Memory – 8GB RAM
  • Single Ethernet – RJ-45, Integrated 10/100/1000 LAN
  • Serial, USB 3.0 & 2.0 ports
  • 2.5” SATA II Solid State Drive – Removable, Shock Resistant – 1500G
  • WiFi – 802.11b,g,n & Bluetooth External
  • Fanless, Enclosed, Heat Pipe Technology
  • 12.1” 1024 x 768 XGA Vehicle Display
  • 0 to 2000 NIT Touch Screen LCD (Adjustable, Less Filters)
  • 12 Programmable LED Backlit Function Buttons
  • 2 USB 2.0 Ports in Front – 2 USB 3.0 Ports in Rear
  • Integrated Stereo Speakers with Adjustable Volume and External Stereo PA Output
  • Aluminum Alloy and Molded ABS Bezel
  • 11.6”(H) x 11.8”(W) x 2.1”(D) at base, 0.9”(D) in screen area
  • Built-in Power Supply with 6.8V~28V Range
  • Secondary HDMI display support
  • -10°C to +65°C

  • Space saving all-in-one design
  • Ruggedized for in-vehicle use
  • Wide range, built-in power supply (no external supply needed)
  • Industry standard daylight viewable touch screen display
  • Low current usage
  • Emergency and A/V kill buttons
  • Programmable power management
  • Optional accessories including mini UPS, card swipe reader among others
